P6.67 Module HD LED Display Front Maintenance Outdoor LED Screen Advertising Board

Product Categories
Shenzhen LED World Co.,Ltd
Contact Now

P6.67 Module HD LED Display Front Maintenance Outdoor LED Screen Advertising Board

  • 1
  • 2

Brand Name : LED WORLD

Model Number : Outdoor iron cabinets

Certification : CE, ROHS

Place of Origin : Shenzhen, China

MOQ : 1sqm

Price : Negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1000pcs per month

Delivery Time : 12- 25 working days

Packaging Details : wooden case , flight case , carton

Cabinet Weight( : 35kg

Pixel pitch : 6.67mm

Cabinet material : Die casting

Viewing distance : >5m

Configuration : RGB

Drive model : 1/8

IP Grade : IP65 or IP67

Function : Advertising

Contact Now

High-Quality P6.67 Module Front Maintenance Outdoor Electronic Advertising LED Screen Panel

Features:

​

  1. High brightness over 7500nits by using Epistar big LED chip ;
  2. High color output: 16-bit color so the video, images are shown on the LED screen is very fresh and vivid. It catches the eyes of more audiences, making your advertising very efficient.
  3. High refresh rate over 3840HZ/S; when you take photos or video, no scanning lines.
  4. High waterproof functions: IP65 front and IP54 back. Our cabinet backdoor has a special cover, no need to make an additional frame to protect waterproof from the rear side.

Advantage:

  1. High reliability: using distributed scanning technology and module design technology that make higher reliability and
  2. stability.
  3. Steady and reliable system: with strong anti-interference ability and long service life that can continually work for over 24
  4. hours, and it's easy to operate the system.
  5. Wide viewing angle: The horizontal and vertical viewing angles are so wide that it is suitable for a wide horizon.
  6. Error detection and monitoring: it can monitor the inner temperature, voltage, cooling fans, etc and error detection automatically.
  7. Environment protection, anti-static, dust-proof, good heat dissipation, cost-effective.
  8. Energy-saving: low electric current,high-bright lamps, equipped with PFC switching power supply that saves

Parameters:

Pixel Pitch 6.67mm
Pixel Density 10000dots/sqm
Color Configuration 1R1G1B
LED Package SMD3535
Module Size 320mm x 160mm
Module Resolution 32dots x 16dots
Drive Mode 1/4Scan, Constant Current
Brightness 7500cd/sqm
Viewing Distance 10m-200m
Interface Port HUB-75
Module Weight 0.4KG/pcs
Viewing Angle H: 120°; V:120°
Refresh Rate 3840HZ
Standard Cabinet Size 960mm x 960mm
Cabinet Weight 35KG/pcs
Frame Rate 120frame/sec
Grey Scale 16.7M colors(Synchronized)
Power Input AC110V/ 220V ±10%, 50HZ
Max Power Consumption 650W/sqm
Ave. Power Consumption 250W/sqm
Working Temperature -20℃~+50℃
Blind Spot Rate <1/10000
Life Span >100,000 Hours
Waterproof IP65
Operating Humidity 10%~95%
Control Method Synchronous, 3G, WIFI, USB
Control PC With DVI Graphic card
Operating System Win 98, Win2000, XP, Win7, Win8 , Win10 etc

Service:

Pre-sale service
1. Reply inquiries in 24 hours.
2. Market research and forecast for customers.
3. Provide professional solutions based on customers' requirements.
4. Offer samples and all documents as customers required.
5. Other services, such as factory visiting and so on.


After-sale service
1. Lifetime maintenance and software upgrade.
2. Complaint response period not exceeding 24 hours, maintenance guidance, and problem solution supplied in 48 hours.
3. Free technician training.
4. Full set of documents free of charge, which includes installation guidance, software operation manual, easy maintenance manual and control system software CD, and so on.
5. Engineer guide installation onsite if needed.

Details:

P6.67 Module HD LED Display Front Maintenance Outdoor LED Screen Advertising BoardP6.67 Module HD LED Display Front Maintenance Outdoor LED Screen Advertising Board
