1R1G1B P4 Outdoor Fixed LED Display Panel MBI5124 IC Iron Cabinet
Features:
Our service:
1, Specific, dedication, professional. It takes nearly 11 years to sharpen a sword. Most of people are seeing we are doing the common products. No! The knowledgeable people or customers who have worked with us together know how our quality is .
2, To meet customers needs. We are able to modify the details of cabinets, adopting advanced technology to update the visional effect.
3, Perfect service. We discuss about product details, solutions, logistics and after-sale service with fluent English communication with customers from A to Z. To make customers feel happy, relieved, free from worry.
4, To help customers make money. Careful inspection, no spares and accessories missed delivery. Let customers save a lot of trouble, save time and effort to maintain old customers/clients, and have more time to develop new customers.
Application:
Our full color LED display are widely used in gas station,financial industry,press conference,internal,athletic contest,factories,hotel,Community centers, stations, backgound,Outdoor Signage and advertisement,trade fair,traffic Control and so on .
Parameter:
| P4 outdoor fixed led display |
| Module Parameter |
| Pixel pitch | 4mm |
| Pixel Density | 62500 pixels/sqm. |
| LED type | SMD1921 black |
| Pixel combination | 1R1G1B |
| Module size | 320x160mm |
| Module resolution | 80x40 pixels |
| Driving mode | 1/10 scan |
| Panel Parameter |
| Number of modules | 2W*4H |
| Panel size | 640x640mm |
| Panel resolution | 160x160 |
| Maintain way | Rear |
| IP Rating | IP65 |
| Flatness | ≤0.1mm |
| Cabinet material | Die-cast aluminium or Iron |
| General Parameter |
| Viewing distance | ≥5M |
| Brightness | ≥6500CD/sqm. |
| Viewing angle | 120°/120° |
| Weight | 40kg/sqm. |
| Max Power consumption | 900W/sqm. |
| Aver Power consumption | 360W/sqm. |
| Frame frequency | ≥60HZ |
| Refresh frequency | ≥1920HZ |
| Working Temperature | -30ºC~50ºC |
| Working Voltage | AC90~260V±20%,50-60HZ |
| Grey scale/color | 16384x16384x16384 |
| Brightness adjustment | 0-255 |
| MTBF | 5000 hours |
| Life | 100000 hours |
| Malfunction dot rate | <0.0001 |
| Control distance | Ethernet cable≤100m, Single mode fiber optic ≤500m, Multimode fiber optic ≤15km |
| Control system |
| Control system | Novastar / Linsn / Colorlight ( Optional ) |
| Input signal | DVI / HDMI / SDI / VGA / S-video / Composite |
| Video processor | VDWALL / RGBlingk / Novastar ( Optional ) |
| Audio system |
| Audio system | BOSE / JBL / PAL / Customized ( Optional ) |
| Installation | Fixed installation / Rental installation ( Optional ) |
| Hanging bar | Optional |
| Certification | CE / RoHS / ETL / CCC / FCC / BS476 |
| Packing Type | Plywood case / Flight case ( Optional ) |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. |
